DIY 3.5" JL Audio dash speaker upgrade - Wow!

Discussion in 'Audio & Video' started by 57HotrodVW, Oct 24, 2018.

  1. May 23, 2019 at 8:04 AM
    #61
    Jagamov

    Jagamov New Member

    Joined:
    May 20, 2019
    Member:
    #9956
    Messages:
    29
    Gender:
    Male
    Vehicle:
    2019 4Runner Limited Nightshade
    Big edit:

    Apparently (and this is on me too) the JBL system in the Limited is totally different. Different speaker and a completely different connector.

    So at this point I’ll be sticking with the stock speakers since I didn’t want to tear apart the stock connector and the JBL speaker in the car didn’t seem too bad.

    Kudos to Crutchfield for being so easy to work with.

    Last edited: Jun 6, 2019
  2. Jun 6, 2019 at 6:47 AM
    #62
    Jagamov

    Jagamov New Member

    Joined:
    May 20, 2019
    Member:
    #9956
    Messages:
    29
    Gender:
    Male
    Vehicle:
    2019 4Runner Limited Nightshade
    BTW, if anyone wants the Taco Tunes adapters, I’ll ship em super cheap. They’ve been cut down to about 6 inches.

  3. Jul 8, 2019 at 3:47 PM
    #63
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
  4. Jul 9, 2019 at 7:11 AM
    #64
    Andason74

    Andason74 New Member

    Joined:
    Jul 9, 2019
    Member:
    #10493
    Messages:
    4
    Gender:
    Male
    Ebay ad indicates tacoma, does this fit 4runner 2019?

    2016 4Runner SR5 likes this.
  5. Jul 9, 2019 at 1:38 PM
    #65
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Yep all the same. Just bought a 2019 Highlander and it's the same on that also. I have to say though, the OEM dash speakers in the Highlander are far superior to the 4Runner and Tacoma. It's a full range woofer, not just a tweeter.

    Andason74 likes this.
  6. Jul 9, 2019 at 1:47 PM
    #66
    nimby

    nimby in the drink

    Joined:
    Mar 27, 2017
    Member:
    #3777
    Messages:
    673
    First Name:
    Jake
    California
    Vehicle:
    2018 SR5P 4WD
    Eibach Adjustable Front Shocks; Trail Wheels; 285/70/R17
    What speaker would you recommend that will work with this plug?

  7. Jul 9, 2019 at 2:06 PM
    #67
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Literally any 3.5" speaker you want. I am running the JBL GTO series 3.5 which sounds great. Same is going in my 2019 Highlander.

    Strandskov and nimby like this.
  8. Jul 29, 2019 at 11:23 PM
    #68
    Strandskov

    Strandskov Take the Road Less Traveled

    Joined:
    Sep 25, 2018
    Member:
    #7288
    Messages:
    1,065
    Gender:
    Female
    First Name:
    Jennifer
    So Cal
    Vehicle:
    2015 Toyota 4Runner SR5
    I know this is an old post but I'm finally coming around and decided to upgrade my sound in my 4runner.

    Is this like some sort of insulation to provide better sound quality?
    So is

  9. Jul 30, 2019 at 1:55 PM
    #69
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Yes, it's fatpat xxx sound deadening. You'll need about 150 square feet to do the whole floor, inner and outer skin of all 4 doors, inner and outer skin of the tailgate, and the roof, inner and outer quarter panels, basically every piece of sheet metal you can get to. You want as much coverage as possible. Gut the interior and have at it. Make sure you have a roller. You have to contour it to all the ripples in the sheet metal otherwise it's pretty much useless.

  10. Aug 2, 2019 at 11:57 AM
    #70
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Chris. Did you have to trim the collar on the speaker? I know you have to trim the dashboard grill, but someone indicated that the JBL require some trimming. Thanks.

  11. Aug 2, 2019 at 12:12 PM
    #71
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Yes I did. Did the same for my 2019 Highlander. Worth the effort IMO, they are much better than the lower end JBL speakers. Club series are a drop in, I tired them in my Highlander, stock sounded better lol. Don't waste your $ on the cheaper stuff.

  12. Aug 2, 2019 at 12:30 PM
    #72
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Figured. I’m looking at the JL and JBL. Also did you buy capacitors or did they come with the speakers. If you bought them, were they the same as Eric used?

  13. Aug 2, 2019 at 12:32 PM
    #73
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    JBL provides the required cap with the speakers. They are 150 UF for reference. The Clue series came with a 250 UF which was way too high. Overall they sounded terrible.

  14. Aug 2, 2019 at 12:47 PM
    #74
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Great. I was going JBL because I was looking at the gTO629s for the front doors (there is a 6x9 speaker that also fits I guess). Anyway I just was worried about cutting off the collar.... do you cut it so that it’s below the rubber?

  15. Aug 2, 2019 at 12:51 PM
    #75
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    I have the JBL GTO629 in the rear doors and tailgate and the GTO939 in the front doors. I cut 75% of it off the 3.5, not below the rubber.

  16. Aug 2, 2019 at 12:56 PM
    #76
    ipnpulz

    ipnpulz New Member

    Joined:
    Oct 14, 2018
    Member:
    #7455
    Messages:
    307
    Gender:
    Male
    Vehicle:
    2019 TRD OR Premium w/KDSS
    Just not posting pictures! :boink::boink:

    nimby likes this.
  17. Aug 9, 2019 at 12:00 PM
    #77
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
  18. Aug 9, 2019 at 1:34 PM
    #78
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
  19. Aug 11, 2019 at 8:08 PM
    #79
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Well. I got the dash speakers replaced with JBL GTO329. I realized my soldering needs improvements. The drivers side was “easy”. The passenger side... tough. I hope my soldered connects hold out over time.

    2016 4Runner SR5 likes this.
  20. Aug 11, 2019 at 8:14 PM
    #80
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    What do you think of them so far?

  21. Aug 11, 2019 at 8:41 PM
    #81
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Hmmm. I’m still in test mode. The first song was a Beatles song with a lot of treble. I’m not sure if it was the song or the installation//speakers. I think it sounds better. Once the door speakers are in I will be happy.

  22. Aug 12, 2019 at 12:26 AM
    #82
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
  23. Aug 12, 2019 at 4:57 AM
    #83
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Yes, you need speaker adaptors for all the doors, front rear and tailgate. The rear doors and tailgate use the same adaptors so buy 4 if you're replacing all 4 speakers.

  24. Aug 12, 2019 at 9:03 AM
    #84
    nimby

    nimby in the drink

    Joined:
    Mar 27, 2017
    Member:
    #3777
    Messages:
    673
    First Name:
    Jake
    California
    Vehicle:
    2018 SR5P 4WD
    Eibach Adjustable Front Shocks; Trail Wheels; 285/70/R17
    Why was the passenger side harder?

  25. Aug 12, 2019 at 3:10 PM
    #85
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    There is a duct in the way.

    nimby likes this.
  26. Aug 18, 2019 at 10:13 AM
    #86
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    One more question on the JBL939. There’s a plastic ring around the speaker. It’s pretty loose. I guess you remove if you use the JBL grill. Did you leave this on when you mounted them in the door?

  27. Aug 18, 2019 at 10:46 AM
    #87
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    I don't remember a ring. That ring is likely supplied for bottom mount in the rear deck of some older cars that way it spaces it down and the surround doesn't touch the metal deck. I mounted the speakers in the aftermarket adaptors and put the door panel back on. There is no reason to use the supplied JBL grill at all.

  28. Aug 18, 2019 at 11:53 AM
    #88
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Cool. Thanks. FYI. Here is my installed speaker and that ring. I’m going without until I hear issues.
    image.jpg image.jpg

    4Runner fun likes this.
  29. Aug 18, 2019 at 11:54 AM
    #89
    2016 4Runner SR5

    2016 4Runner SR5 New Member

    Joined:
    Jan 29, 2017
    Member:
    #3447
    Messages:
    522
    Gender:
    Male
    First Name:
    Chris
    Maryland
    Vehicle:
    2016 4Runner SR5, tech package, MGM
    Bought it 1/29/17 TRD Pro suspension with spacer, 285/70/17 Falken AT3W, FX Pro wheels
    Yes, remove that ring. The ring is to be used if you were mounting the speaker from behind or under a panel. It just acts as a spacer and is not needed for our application.

  30. Aug 19, 2019 at 11:50 AM
    #90
    Jkdog

    Jkdog New Member

    Joined:
    Mar 2, 2019
    Member:
    #9017
    Messages:
    133
    Gender:
    Male
    Vehicle:
    2019 Off-Road Premier
    Thanks for the help. New speakers from front to tailgate. Still more sound from the dash speakers than the door speakers. Would love to control them separate from the front door speakers. But I’ll live with it. Still sounds great.

    As I mention in another post, if you replace the rear door speakers, getting the door panels back on is a bear!!! The front doors were difficult but I did it in one push. The rear door I had to walk away and calm down. Patience is needed.

    2016 4Runner SR5 and 4Runner fun like this.
